applications
Fire performance cables are used in a variety of critical applications, including:
● Fire Alarm Systems: Ensuring reliable operation of fire detection and alarm systems.
● Emergency Lighting: Maintaining illumination during power outages caused by fire.
● Communication Systems: Supporting continuous communication for emergency services.
● Life Safety Systems: Powering essential safety systems in hospitals, airports, and other public facilities.
● Control Circuits: Ensuring the operation of vital control systems in industrial environments.
Construction
Fire performance cables are constructed with high-quality materials designed to resist fire and minimize smoke and toxic gas emissions. Key components include:
● Conductors: Made of copper or aluminum, providing excellent electrical conductivity.
● Insulation: High-temperature resistant materials such as mica tape, silicone rubber, or LSZH (Low Smoke Zero Halogen) compounds.
● Sheathing: Fire-resistant outer sheath made of LSZH or other flame-retardant materials.
● Armoring: Optional steel wire or tape armoring for additional mechanical protection.
● Fire Barriers: Fire Barriers: Mica tape or other fire-resistant barriers to prevent fire propagation.
Types of Fire Performance Cables
Fire Resistant Cables
● Construction: These cables typically feature mica tape or other fire-resistant barriers around the conductor, high-temperature insulation, and a durable outer sheath.
● Applications: Used in critical systems requiring continuous operation during a fire, such as fire alarms and emergency lighting.
● Standards: Compliant with IEC 60331 for circuit integrity under fire conditions.
Low Smoke Zero Halogen (LSZH) Cables
● Construction: Insulated and sheathed with LSZH compounds that emit minimal smoke and toxic gases when exposed to fire.
● Applications: Ideal for use in public buildings, transportation systems, and areas with high human occupancy where smoke inhalation and toxicity are concerns.
● Standards: Meets IEC 61034 for smoke emission and IEC 60754 for halogen-free properties.
Flame Retardant Cables
● Construction: Designed with flame-retardant materials to prevent the spread of fire along the cable.
● Applications: Used in general building wiring and installations where flame spread must be controlled.
● Standards: Adheres to IEC 60332 for flame retardance.
Standards
BS 6387
Title: Test Method for Resistance to Fire of Cables Required to Maintain Circuit Integrity under Fire Conditions
Scope: This British Standard specifies test methods for cables required to maintain circuit integrity under fire conditions, covering resistance to fire with water and mechanical shock.
IEC 60331
Title: Tests for Electric Cables under Fire Conditions – Circuit Integrity
Scope: Specifies test procedures for assessing the circuit integrity of electric cables under fire conditions, ensuring cables can function for a specified period during a fire.
IEC 60332
Title: Tests on Electric and Optical Fibre Cables under Fire Conditions
Scope: Describes test methods for assessing the flame propagation characteristics of electric and optical fiber cables, ensuring they do not contribute to the spread of fire.
IEC 61034
Title: Measurement of Smoke Density of Cables Burning under Defined Conditions
Scope: Specifies test methods for measuring the density of smoke emitted by cables when burned under defined conditions, ensuring minimal smoke production.
IEC 60754
Title: Test on Gases Evolved during Combustion of Electric Cables
Scope: Specifies procedures for determining the amount of halogen acid gas and other toxic gases evolved during the combustion of cables, ensuring safety in fire scenarios.
